Specs
- Transmission Speeds Infinitely Variable
- Engine Brand Kawasaki
- Transmission Brand Hydro-Gear
- Engine Brand Kawasaki
- Engine Model FX730V
- Engine Displacement 725
- Transmission Hydrostatic
- Engine Series V-Twin
- Fuel System Carbureted
- Speed Infinitely variable speed selection 0–8.5 mph (x.x kmph) forward, 0–x.x mph (x.x kmph) reverse
- Engine Speed 3,750 rpm
- Air Filter Heavy-duty canister air filtration system
- Fuel Capacity 8-gallon (xx.x-L), single fuel tank on LH side.
- Drive Description Two Hydro-Gear 12 cc pumps powering two Parker 14.5 cubic inch motors.
- PTO Engagement Warner 200 ft-lb clutch
- Fuel Type Gas Carbureted
- Drive System HYDRO
- Fuel Indicator Yes - Float Gauge
- Drive Wheel Release Allows unit movement without engine running.
- Deck Lift Single point HOC; with mechanical lift-assist springs.
- Carb Compliant NO
- Safety Package Operator Presence Controls (OPC) with safety interlock system indicators
- UPC 193308221816
- Starter Electric
- Steering Control Twin levers with center fixed reference bar for ease of control forward and reverse
- Front Caster Tires 13 x 5.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
- Drive Tires 20x10.0-8 Carlisle Turf Master
- Parking Brake Lever-actuated bar brake.
- Tractor Frame Welded, heavy-duty 1.5" x 2.5" tubular steel.
- Blade Spindles No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.
- Electrical 12-volt battery with 15-amp alternator.
- Cup Holder Yes
- Standard Features Enhanced Engine Hour Meter
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
- Width / Cutting Deck 60"
- Deck Construction 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt
- Cutting Heights 1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (0.64 cm) increments adjustable from operator’s platform.
- Blade Tip Speed Approximately 18,500 fpm.
- Blades 3 Blades at 20.50" Length
- Width 72.87
- Height 49.2
- Length 68.24
- Curb Weight 978
