- Steering Control Hydro drive with Enhanced Control System (ECS), forward/reverse, left/right or zero-turn.
- Caster Forks .38" thick caster yoke arms
- Front Caster Tires 11 x 4.0-5, smooth tread, semi-pneumatic.
- Drive Tires 18 x 8.5-8, 4-ply Turf Master®
- Safety Package Operator Presence Controls (OPC). Operator must have speed control lever in neutral and blades disengaged to leave operator’s position without stopping engine
- Parking Brake Lever-actuated mechanical compression.
- Electrical 12-volt battery with 20-amp alternator.
- Standard Features Enhanced engine hour meter
- UPC 193308000152
- Engine Model ECV650
- Engine Brand Kohler
- Engine Series Command™ EFI
- Engine Speed 3,600 rpm
- Air Filter Heavy-duty canister air filtration system
- Drive Description Twin Hydro-Gear variable-displacement pumps and twin high-efficiency Parker/Ross wheel-drive motors with 1" (2.54cm) tapered shafts.
- Speed Infinitely variable speed selection from 0– 6.75 mph (10.9 kmph) forward, 0–2.25 mph (3.6 kmph) reverse.
- PTO Engagement Electromagnetic 200 ft-lbs clutch.
- Fuel Capacity 5-gallon (18.9-L) fuel tank.
- Drive Wheel Release Allows unit movement without engine running.
- Deck Lift Manual lift with hairpin from hole to hole for position adjustment.
- Fuel System Electronic Fuel Injected
- Engine Displacement 694
- Drive Hydro-Drive
- Fuel Indicator None
- Carb Compliant No
- Fuel Type Gas EFI
- Engine Spec 3017
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
- Width / Cutting Deck 60"
- Deck Construction 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 10-gauge formed and welded spindle mounting locations for improved strength.
- Cutting Heights 1.5" (3.8 cm) to 4.5" (11.4 cm) in 0.5" (1.3 cm) increments.
- Blade Spindles No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.
- Blade Tip Speed Approximately 18,500 fpm.
- Bag Capacity 3 Blades at 20.5" Length
- Blades 3 Blades at 20.5" Length
- Width 73.0 in. (185.4 cm)
- Length 104.8 in. (266.2 cm)
- Height 45.0 in. (114.3 cm)
- Curb Weight 840
