- Blade Spindles No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.
- Drive Tires 24 x 12-12, 4 ply Turf Master®
- Front Caster Tires 13 x 6.5-6, smooth-tread, semi-pneumatic.
- Caster Forks .50" thick caster yoke arms.
- Tractor Frame Unibody, welded, heavy-duty 1.5" x 3" tubular steel.
- Steering Control Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
- Parking Brake Lever-actuated disc brake.
- Seat Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
- Electrical 12-volt battery with 20-amp alternator.
- Onboard Intelligence Smart Controller
- Standard Features Engine hour meter and cup holder
- UPC 193308000572
- Engine Brand Kohler
- Engine Model ECV749
- Engine Displacement 747
- Engine Series Command™ EFI
- Engine Speed 3,750 RPM
- Air Filter Heavy-duty canister air filtration system
- Fuel Type Gas EFI
- Fuel Capacity 12-gallon (45.4-L), single fuel tank with single fill location.
- Fuel Indicator Yes - electronic Sender
- Drive Hydro-Drive
- Drive Description Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 12 cc pumps and 14. 5 cubic inch motors.
- Speed Infinitely variable speed selection from 0–10.0 mph (16 kmph) forward, 0–6.0 mph (9.7 kmph) reverse.
- Carb Compliant Yes
- Deck Lift Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
- Safety Package Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
- ROPS 2-post foldable ROPS standard with seat belt and latch.
- PTO Engagement MagStop electromagnetic 200-ft-lb clutch with spot brake
- Drive Wheel Release Allows unit movement without engine running.
- Engine Spec 3064
- Width / Cutting Deck 60"
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
- Deck Construction 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.
- Blade Tip Speed Approximately 18,500 fpm.
- Cutting Heights 1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments adjustable from operator’s seat.
- Blades 3 Blades at 20.50" Length
- Width 72.8 in. (184.9 cm)
- Length 83.1 in. (211.1 cm)
- Height 70.5 in. (179.1 cm)
- Curb Weight 1177
