Specs
| Cutting | |
|---|---|
| Cutting Height | 4" |
| Cutting Width | 26" |
| Number of Blades | 1 |
| Dimensions | |
|---|---|
| Handlebar Height | 38.7" |
| Height | 42" |
| Length | 74" |
| Shipping Weight | 370 lbs (Man.-Start); 385 lbs (Elec.-Start) |
| Weight | 313 lbs |
| Engine | |
|---|---|
| Air Filter | Dual Element |
| Cooling Methods | Air Cooled |
| Displacement | 389cc |
| Engine Type | OHV |
| Horsepower | 10.2 HP |
| Lubrication | Pressure & Splash |
| Make | Honda |
| Model | GXV390 |
| Number Of Cylinders | 1 |
| Oil Capacity | 38.4oz |
| Oil Type | SAE 30W HD |
| RPM Speeds | 3500rpm |
| Starting Type | Electric |
| Fuel_System | |
|---|---|
| Fuel Capacity | .55 gal |
| General | |
|---|---|
| Accepts Attachments | No |
| CARB Certified | No |
| Assembly | None |
| Wheels_Tires | |
|---|---|
| Number of Tires | 2 |
| Tire Size | 16" x 5.5" |
| Tread | Directional Tread |
| Warranty | |
|---|---|
| Engine Warranty | 3 Year Residential / 3 Year Commercial |
| Machine Warranty | 2 Year Residential /2 Year Commercial |
| Material | |
|---|---|
| Deck | 12 Gauge |
| Frame | Steel |
| Frame Thickness | 11 Gauge |
