Specs
Clutch | |
---|---|
Clutch | Yes |
Cutting | |
---|---|
Number of Teeth | 8 |
Tooth RPM | 2800 |
Dimensions | |
---|---|
Handlebar Height | Adjustable at 33in, 37in, 40in |
Height | 39in |
Length | 51in |
Shipping Weight | 233 lbs |
Weight | 187 lbs |
Width | 29in |
Shipping Dimensions | 54.75inL x 35.5inW x 45.25inH |
Engine | |
---|---|
Air Filter | Paper |
Cooling Methods | Air |
Displacement | 389 cc |
Engine Shaft Diameter | 1" |
Engine Type | OHV |
Ft Lbs Torque | *19.6 ft-lbs gross torque (per SAE J1940) |
Horsepower | 11.7 HP |
Lubrication | Splash |
Make | DR |
Number Of Cylinders | 1 |
Oil Capacity | 37 oz |
Oil Filter | No |
Oil Type | 30W HD |
Pre Cleaner | Yes |
Starting Type | Electric |
Choke/Primer | Choke |
Fuel_System | |
---|---|
Fuel Capacity | 3.2 Qrts |
Fuel Shutoff Valve | Yes |
General | |
---|---|
CARB Certified | Yes |
Assembly | Yes |
Optimized Using FEA For Strength | Yes |
Wheels_Tires | |
---|---|
Brake | Yes |
Dimensions | 15 x 4.75" |
Number of Tires | 2 |
Tire Size | 15in x 4.75in |
Tread | Saw Tooth |
Wheel Brake with Lock | Yes |
Warranty | |
---|---|
Engine Warranty | 2 yrs Residential Use / 90 days Commercial |
Machine Warranty | 2 yrs Residential Use / 90 days Commercial |
Material | |
---|---|
Cutting Blade Material | Replaceable carbide tipped teeth |
Frame | 12 gauge |
Grease Fittings | Yes |
Handlebar Style | Height adjustable (with tools) 33", 37", 40" |
