Specs
Width / Cutting Deck
52"
Drive
Hydro-Drive
Starter
Electric
Steering Control
Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.
Caster Forks
.50" thick caster yoke arms.
Front Caster Tires
13 x 6.5-6, smooth tread, pneumatic. Sealed ball bearings.
Drive Tires
24 x 9.5-12, 4 ply Super Turf TL
Safety Package
Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
Parking Brake
Lever actuated internal wet disc brake
Tractor Frame
Unibody, welded, heavy-duty 1.5" x 3" tubular steel.
Blade Spindles
No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.
Electrical
12-volt battery with 15-amp alternator.
Standard Features
Engine hour meter and cup holder
Seat
Deluxe suspension seat, foam flip-up armrests, and integral safety switch. Adjustment: Fore and aft from operator's position.
Engine Brand
Kawasaki®
Transmission Speeds
Infinitely Variable
Engine Model
FX801V
Engine Displacement
852cc
Engine Series
V-Twin
Fuel System
Carbureted
Speed
Infinitely variable speed selection from 0–11.0 mph (16 kmph) forward, 0–6.0 mph (9.7 kmph) reverse.
Engine Speed
3750 RPM
Engine Spec
FX801-AS31-R
Air Filter
Heavy-duty canister air filtration system
Fuel Capacity
9.5-gallon single fuel tank with single fill location
Drive Description
Dual Hydro-Gear ZT-4400, hydrostatic transmission with charge pumps, relief valves and independent, replaceable filters.
PTO Engagement
MagStop Electromagnetic 175 ft-lb clutch with spot brake
Fuel Type
Gas Carbureted
Fuel Indicator
Mechanical float
Drive Wheel Release
Allows unit movement without engine running.
Deck Lift
Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
Carb Compliant
No
ROPS
2-post foldable ROPS standard with seat belt and latch.
Deck Style
Floating Deck
Deck Style Description
Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
Deck Construction
10-gauge high strength alloy top that is formed and continuously seam welded, with 7-gauge side skirt, and 7-gauge reinforcement plate welded to spindle mounting locations for improved strength.
Cutting Heights
1.5" to 5.5" in 0.25" increments
Blade Tip Speed
Approximately 18,500 fpm
Blades
3 blades at 18.00" length
Width
64.7"
Height
70.1"
Curb Weight
1037
Length
84.6"
