Specs
| Dimensions | |
|---|---|
| Bed Height | 24" |
| Flywheel Diameter | 18 1/4" |
| Flywheel Weight | 55 lbs |
| Height | 46" |
| Length | 79" |
| Shipping Weight | 375 lbs |
| Wedge Height | 6.2" |
| Wedge Width | 3/4" |
| Weight | 235 lbs |
| Width | 25" |
| Shipping Dimensions | 66" L x 29"W x 44"W |
| Working Height | 24" |
| General | |
|---|---|
| CARB Certified | N/A |
| Assembly | Yes |
| Wheels_Tires | |
|---|---|
| Number of Tires | 2 |
| Tire Size | 11" x 4" |
| Tread | Turf |
| Wheel | Steel Wheel with Taper Roller Bearings |
| Warranty | |
|---|---|
| Engine Warranty | 2 yrs Residential Use, 90 days Commercial |
| Machine Warranty | 2 yrs Residential Use, 90 days Commercial |
| Towing | |
|---|---|
| Towable | Yes |
| Splitting | |
|---|---|
| Average Cycle Time | 2.5 Sec's |
| Flywheel Max RPM | 400 |
| Max Log Diameter | 30" |
| Max Log Length | 18" |
| Outsplits | 22 Ton Hydraulic Splitter |
| Motor | |
|---|---|
| Motor | 120V, 1800W, 15amp |
| Material | |
|---|---|
| Frame | 1/4" thick steel |
